★SPBB1 Series pumps, are single-stage double suction split case centrifugal pumps designed for applications of clean water or similar liquids without solids in water works, municipal and industrial projects, as well as mines, power plants and agricultural irrigations etc.
The horizontal installation constructed with the suction and discharge nozzles located in the lower part and in right angle of the pump shaft central line, make it convenient to pull out the rotor after removing the pump cover when maintaining and repairing without disturbing the inlet and outlet piping. Medium contacted parts are selectable from ductile cast iron, cast steel and stainless steel upon request.
★Standardized design with generalized products series.
★Double volute casing construction perfectly balances the radial forces, ensuring minimal shaft deflection lowered bearing loads.
★Double suction impeller design appropriately balances the axial forces with each impeller balanced statically and dynamically in accordance with ISO1940.
★Flanges are drilled to meet GB, ISO, DIN, BS or ANSI standards.
★Deep groove ball bearings are grease lubricated and sealed for life with optional oil lubrication available upon request.
★Shaft sealing with uncoiled soft packing or single-action unbalanced mechanical seal in accordance with DIN 24960, independent of rotation direction. Balanced mechanical seal shall be applied for operating pressures higher than 16 Bar.
Performance Data
Pump Size: DN 80 ~ 800
Flow Range: Q up to 2800l/s
Head Range: H up to 220m
Operating Pressure: P up to 25 Bar
Liquid Temperature: T up to 300°C
