Introduction:
HY series chemical submerged pump is a
centrifugal pump of single stage, end suction design, designed for transmitting
toxic, corrosive liquid stored underground in the petrochemical, chemical,
metallurgical, depot, sewage treatment industries, etc. It adopts mature design
of IJ series chemical process pump, and owns the same hydraulic performance as
the IJ series pump.
Application:
Clean liquid or corrosive liquid
containing small quantities of solid particles and crystalline mass.
Open
type impeller, conveying pulp with the concentration less than 8% and gypsum
pulp with solid content less than 30%.
Wear-resistance material, suitable for
conveying bentonite, abrasive tool, lime milk, lime stone gypsum, and
sand-containing crude oil etc.
High temperature, high concentration under the
acid conditions, such as the sulfuric acid.
Performance Range:
Capacity: 0.3~2400m3/h
Total
head: 5~230m
Working temperature: -40~400 degree Celsius
Max working
pressure: 2.5MPa
Conform to API610 OH2 standard,
API610VS4/VS5
Pump
Feature:
Immersion in liquid, pump self-suction capacity,
operation without filling water;
Start or stop at any time, convenient use;
No seal, no leakage, safety and environmental protection;
A high degree
of generalization, modular design for main parts such as base plate, supporting
tube, shaft, shaft housings, greatly reducing storage of the spare
parts,
Prevention of sundries due to filter.
